Product Overview
Applications:
Pallet Assembly, Crate Assembly, Wall Panel Assembly
Features:
- Contact Actuation
- Front Exhaust
- Side Load Nylon Magazine
- Body Protector
- Narrow Nose for Accurate Nail Placement
- Protective Dust Cover
- Ergonomic Rubber Grip
- Air Fitting Included
Includes:
Air Fitting, Allen Wrenches, Safety Glasses, Tool Oil
Available Accessories:
Remote Valve (RE-MXRCV70)
Specifications:
| Diameter | .090 - .113 |
| Fastener Length | 1-3/4” - 2-3/4” |
| Magazine Capacity | 300 |
| Actuation Mode | Contact Actuation |
| Dimensions | 13-1/2” x 5” x 12-3/4” |
| Weight | 8.2 lbs |
| Operating Pressure | 80-110 PSI |
| Air Inlet NPT | 1/4” |
| Air Consumption per Cycle @ 90 PSI | 0.087 SCF |
| Noise Power Emissions per EN12549 LwA,1s | 112.4 dBA |
| Noise Pressure Emissions per EN12549 LpA,1s | 101.7 dBA |
| Vibration Value per ISO-8662-11 | 14.55 m/s² |
| Vibration Value Uncertainty per ISO-8662-11 | 1.50 m/s² |
